Thyristor power controllers
Our quote will always be lower than the manufacturer's price. Please send us the full part number of a device to get a quick response.
REVO TC is a Compact Solution that Integrate Temperature and Power Controller in One Unit with single, two or three phase.
- Suitable for Normal Resistance load types
- From 30A to 45A
- Max. voltage 480V, 600Vac
- Load type: Resistance
- Inputs: Pt100, Thermo Couple, 0:10V, 4:20mA
- Heather Break alarm options
- Firing mode: Zero Crossing
- Suitable for Normal Resistance load types
- Supply voltage up to 480V, 600Vac
- Microprocessor based electronic circuit fully isolated from the power
- Thyristor Firing types include Zero Crossing Firing
- Controller input signals from Thermocouple, PT100 (3 wire RTD), 4-20mA and 0-10V DC Linear
- Up to 4 configurable Controller outputs (Relay, SSR and 4-20mA)
- Heater Break (HB) alarm to diagnose partial or total load failure with automatic setting, relay alarm output and front LED indication. Available as an option
- Internal quick-blow fuses as standard
- RS485 comms (Modbus Protocol) as standard
- Internal Current Transformer included as standard
- Special design Heatsink with high dissipation value
- IP20 protection
- Complies with CE specification
- Single Loop PID Temperature controller
- Current Transformers
- Fuse-Holder
|
REVO TC is a Compact Solution that Integrate Temperature and Power Controller in One Unit with single, two or three phase.
- Suitable for Normal Resistance load types
- From 60A to 210A
- Max. voltage 480V, 600Vac
- Load type: Resistance
- Inputs: Pt100, Thermo Couple, 0:10V, 4:20mA
- Heather Break alarm options
- Firing mode: Zero Crossing
- Suitable for Normal Resistance load types
- Supply voltage up to 480V, 600Vac
- Microprocessor based electronic circuit fully isolated from the power
- Thyristor Firing types include Zero Crossing Firing
- Controller input signals from Thermocouple, PT100 (3 wire RTD), 4-20mA and 0-10V DC Linear
- Up to 4 configurable Controller outputs (Relay, SSR and 4-20mA)
- Heater Break (HB) alarm to diagnose partial or total load failure with automatic setting, relay alarm output and front LED indication. Available as an option
- Internal quick-blow fuses as standard
- RS485 comms (Modbus Protocol) as standard
- Internal Current Transformer included as standard
- Special design Heatsink with high dissipation value
- IP20 protection
- Complies with CE specification
- Single Loop PID Temperature controller
- Current Transformers
- Fuse-Holder
|
